产品详情
| CPU Socket | LGA1151 |
| CPU | 7th/6th Gen Intel® Xeon E3/Core™ i7/i5/i3/ Pentium® / Celeron® QC/ DC processors, up to 4.2GHz |
| PCH | MB991AF-C236: Intel® C236 PCH MB991AF: Intel® Q170 PCH |
| Memory | 4x DDR4 DIMM, Max. 64GB (supports ECC by CPU SKUs) |
| BIOS | AMI |
| Watchdog Timer | 256 levels |
| H/W Monitor | Yes |
| Storage Device Interface | 1x mSATA via Mini PCI-E (thru SATA III) 1x M.2 slot [thru PCI-E (x1) x4](NVMe) |
| Expansion Slots | 1x PCI-E (x16), 1x PCI-E (x8), 1x PCI-E (x4) 1x M.2 (2280) |
| Mini Type Slots | 1x Mini PCI-E |
| Graphics Controller | 7th/6th Gen Intel® Core™ i7/i5/i3/ Pentium®/ Celeron® processor Integrated |
| Video Output | 2x HDMI (1.4) and LVDS |
| Ethernet | Intel® I219LM Gigabit LAN PHY Intel® I211AT or I210AT Gigabit LAN |
| I/O Chip | Fintek F81846AD-I + F81504D |
| Serial Port | 6x RS232, 2x RS232/422/485 (jumper-less selection) |
| USB 2.0 | 4x USB 2.0 via pin-header |
| USB 3.X | 6x USB 3.0 on board |
| Serial ATA | 5x SATA III |
| Audio | Intel® C236 / Q170 PCH built-in HD audio + Realtek ALC888S codec |
| TPM | TPM (2.0) |
| Others | Digital I/O (4-in/4-out), RAID, iAMT (11.6), iSMART |
| Dimensions (L x W) | 244mm x 244mm (9.6" x 9.6") |
| Power Consumption | Intel® Core i7-6700, 3.4GHz, w/ 4x 8GB DDR4-2133 12V: 7.1A +5V: 1.81A +5VSB: 0.11A +3.3V, 0.70A |
| Operating Temperature | 0°C~60°C ( 32°F~140°F ) |
| Storage Temperature | -20°C~80°C ( -4°F~176°F) |
| Relative Humidity | 90% (non-condensing @60°C) |
